###### Global Parameters #########
xlog_level=4
#debug_mode=yes
stderror_enabled=yes
syslog_facility=LOG_LOCAL0
# Set up listeners
#socket=tls:127.0.0.1:5261
socket=udp:172.16.4.111:5260
socket=udp:172.16.4.111:5261
####### Modules Section ########
# set module path
mpath="/usr/local/lib64/sbc/modules/"
#### SIGNALING module
loadmodule "signaling.so"
loadmodule "db_mysql.so"
#### StateLess module
loadmodule "sl.so"
#### Transaction Module
loadmodule "tm.so"
modparam("tm", "fr_timeout", 5)
modparam("tm", "fr_inv_timeout", 30)
modparam("tm", "restart_fr_on_each_reply", 0)
modparam("tm", "onreply_avp_mode", 1)
#### Record Route Module
loadmodule "rr.so"
modparam("rr", "append_fromtag", 0)
#### MAX ForWarD module
loadmodule "maxfwd.so"
#### SIP MSG OPerationS module
loadmodule "sipmsgops.so"
#### FIFO Management Interface
loadmodule "mi_fifo.so"
modparam("mi_fifo", "fifo_name", "/tmp/opensips_fifo")
modparam("mi_fifo", "fifo_mode", 0666)
loadmodule "httpd.so"
loadmodule "mi_http.so"
modparam("httpd","port",9998)
#### USeR LOCation module
loadmodule "usrloc.so"
modparam("usrloc", "nat_bflag", "NAT")
modparam("usrloc", "working_mode_preset", "single-instance-sql-write-back")
modparam("usrloc", "db_url", "mysql://opensips:opensipsrw@172.16.4.111/opensips")
#### REGISTRAR module
loadmodule "registrar.so"
#### RTPengine protocol
loadmodule "rtpengine.so"
modparam("rtpengine", "rtpengine_sock", "udp:172.16.4.111:2222")
#### Nathelper protocol
loadmodule "nathelper.so"
modparam("registrar|nathelper", "received_avp", "$avp(rcv)")
#### UDP protocol
loadmodule "proto_udp.so"
loadmodule "proto_tcp.so"
#### TLS protocol
#loadmodule "proto_tls.so"
#### WebSocket and WebSocketSecure protocol
#loadmodule "proto_wss.so"
loadmodule "proto_ws.so"
####### Routing Logic ########
# main request routing logic
route{
if (!mf_process_maxfwd_header(10)) {
sl_send_reply(483,"Too Many Hops");
exit;
}
if (has_totag()) {
# sequential requests within a dialog should
# take the path determined by record-routing
if (loose_route()) {
if (is_method("INVITE")) {
# even if in most of the cases is useless, do RR for
# re-INVITEs alos, as some buggy clients do change route set
# during the dialog.
record_route();
}
xlog("L_DBG","[$cfg_line][$ci]---has-tag-:$rm|$rs|$tu|$socket_in(port)|$var(contact)\n");
if ($si == "172.16.4.114") {
$socket_out="udp:172.16.4.111:5261";
} else {
$socket_out="udp:172.16.4.111:5260";
}
# route it out to whatever destination was set by loose_route()
# in $du (destination URI).
route(relay);
} else {
if ( is_method("ACK") ) {
if ( t_check_trans() ) {
# non loose-route, but stateful ACK; must be an ACK after
# a 487 or e.g. 404 from upstream server
t_relay();
exit;
} else {
# ACK without matching transaction ->
# ignore and discard
exit;
}
}
sl_send_reply(404,"Not here");
}
exit;
}
# CANCEL processing
if (is_method("CANCEL")) {
if (t_check_trans())
t_relay();
exit;
}
t_check_trans();
#if (!is_method("REGISTER")) {
# if (is_myself("$fd")) {
# # if caller is not local, then called number must be local
# if (!is_myself("$rd")) {
# send_reply(403,"Rely forbidden");
# exit;
# }
# }
#}
# preloaded route checking
if (loose_route()) {
xlog("L_ERR",
"Attempt to route with preloaded Route's [$fu/$tu/$ru/$ci]");
if (!is_method("ACK"))
sl_send_reply(403,"Preload Route denied");
exit;
}
# record routing
if (!is_method("REGISTER|MESSAGE"))
record_route_preset("172.16.4.111:5260");
if (!is_myself("$rd")) {
append_hf("P-hint: outbound\r\n");
route(relay);
}
# requests for my domain
if (is_method("PUBLISH|SUBSCRIBE")) {
sl_send_reply(503, "Service Unavailable");
exit;
}
# check if the clients are using WebSockets or WebSocketSecure
if ( $socket_in(proto) == "WS"|| $socket_in(proto) == "WSS")
setflag("SRC_WS");
# consider the client is behind NAT - always fix the contact
fix_nated_contact();
xlog("L_DBG","[$cfg_line][$ci]---main-1-:$rm|$rs|$tu|$socket_in(port)|$var(contact)\n");
if (is_method("REGISTER")) {
# indicate that the client supports DTLS
# so we know when he is called
if (isflagset("SRC_WS"))
setbflag("DST_WS");
fix_nated_register();
if (!save("location"))
sl_reply_error();
exit;
}
xlog("L_DBG","[$cfg_line][$ci]---main--:$rm|$rs|$tu|$socket_in(port)|$var(contact)\n");
if ($rU==NULL) {
# request with no Username in RURI
sl_send_reply(484,"Address Incomplete");
exit;
}
if ($si != "172.16.4.114") {
$du = "sip:172.16.4.114:5060";
$socket_out="udp:172.16.4.111:5260";
}
# # do lookup with method filtering
# if (!lookup("location","method-filtering")) {
# t_newtran();
# t_reply(404, "Not Found");
# exit;
# }
route(relay);
}
route[relay] {
# for INVITEs enable some additional helper routes
if (is_method("INVITE")) {
t_on_branch("handle_nat");
t_on_reply("handle_nat");
} else if (is_method("BYE|CANCEL")) {
rtpengine_delete();
}
if (!t_relay()) {
send_reply(500,"Internal Error");
};
exit;
}
branch_route[handle_nat] {
xlog("L_INFO","[$cfg_line][$ci]--m01---:$rm|$rs|$tu|$rU|$fU|$si|$socket_in(proto)|$socket_in(port)\n");
if (!is_method("INVITE") || !has_body("application/sdp"))
return;
$var(rtp_flag) = "replace-origin ";
if (isflagset("SRC_WS") && isbflagset("DST_WS")) { #web->web
$var(rtp_flag) = $var(rtp_flag) + " ICE=force-relay DTLS=passive";
} else if (isflagset("SRC_WS") && !isbflagset("DST_WS")){ #web->sip
$var(rtp_flag) = $var(rtp_flag) + " codec-strip-G722 codec-strip-CN codec-strip-red strip-extmap rtcp-mux-demux DTLS=off SDES-off ICE=remove RTP/AVP";
} else if (!isflagset("SRC_WS") && isbflagset("DST_WS")) {#sip->web
$var(rtp_flag) = $var(rtp_flag) + " rtcp-mux-offer generate-mid DTLS=passive SDES-off ICE=force RTP/SAVPF";
} else if (!isflagset("SRC_WS") && !isbflagset("DST_WS")) #sip->sip
$var(rtp_flag) = $var(rtp_flag) + " DTLS=off SDES-off ICE=remove RTP/AVP";
rtpengine_offer("$var(rtp_flag)");
}
onreply_route[handle_nat] {
xlog("L_INFO","[$cfg_line][$ci]--onreply-route---:$rm|$rs|$tu|$rU|$fU|$si|$socket_in(proto)|$socket_in(port)\n");
if (is_present_hf("Record-Route")) {
remove_hf("Record-Route");
append_hf("Record-Route: <sip:172.16.4.111:5261;lr>\r\n");
xlog("L_INFO","has record-route..\n");
}
fix_nated_contact();
if (!has_body("application/sdp"))
return;
$var(rtp_flag) = "replace-origin ";
if (isflagset("SRC_WS") && isbflagset("DST_WS")) #web->web
$var(rtp_flag) = $var(rtp_flag) + " ICE=force-relay DTLS=passive";
else if (isflagset("SRC_WS") && !isbflagset("DST_WS")) #web->sip
$var(rtp_flag) = $var(rtp_flag) + " codec-strip-G722 codec-strip-CN codec-strip-red codec-strip-opus rtcp-mux-offer generate-mid DTLS=passive SDES-off ICE=force";
else if (!isflagset("SRC_WS") && isbflagset("DST_WS")) #sip->web
$var(rtp_flag) = $var(rtp_flag) + " rtcp-mux-offer generate-mid DTLS=passive SDES-off ICE=remove RTP/AVP";
else if (!isflagset("SRC_WS") && !isbflagset("DST_WS")) #sip->sip
$var(rtp_flag) = $var(rtp_flag) + " DTLS=off SDES-off ICE=remove RTP/AVP";
rtpengine_answer("$var(rtp_flag)");
}
|
