keepalived 配置虚拟ip

背景

不管是什么业务服务，当需要做主备方案时，一般都会采用keepalived的虚拟ip方式来切换。

本章采用容器部署方式，不检查业务服务是否正常，主服务器宕机或者停止keepalived容器来切换虚拟ip到备用机器上。

keepalived的版本信息:

2.3.1

容器镜像制作

我使用centos7.9做基础镜像,源码编译keepalived, dockerfile如下:

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19


FROM  centos:centos7

WORKDIR /data

COPY . .

# RUN yum makecache -y && yum clean all -y
RUN cp ./third-package/CentOS-Base-amd64.repo /etc/yum.repos.d/CentOS-Base.repo -f  && yum makecache -y && yum clean all -y
RUN yum install -y epel-release && yum -y update  &&  yum install -y net-tools vim nginx gcc openssl-devel popt-devel rsyslog gettext nc libnl3 libnl3-devel autoconf libtool
RUN  cd third-package && tar -zxvf automake-1.16.5.tar.gz && cd automake-1.16.5 && ./configure \
    && make -j $(nproc) all  && make install -j $(nproc) \
    && cd .. && rm automake-1.16.5 automake-1.16.5.tar.gz -rf
RUN cd keepalived-2.3.1 && ./configure --prefix=/usr/local/keepalived && make -j $(nproc) all  && make install -j $(nproc)
RUN cp keepalived-2.3.1/keepalived/etc/init.d/keepalived /etc/init.d/ &&\
    cp /usr/local/keepalived/sbin/keepalived /usr/sbin/ &&  \
    chmod +x /data/scripts/*.sh && \
    find . -mindepth 1 ! -path "./scripts" ! -path "./scripts/*" ! -name "entrypoint.sh" ! -path "./conf" ! -path "./conf/*" -exec rm -rv {} + || true

ENTRYPOINT [ "./entrypoint.sh" ]

可以看到，要下载CentOS-Base-amd64.repo(阿里云镜像源)和automake-1.16.5.tar.gz。

scripts目录下有:vip_down.sh,vip_up.sh,

vip_down.sh

1
2
3
4


#!/bin/bash
LOG_OUT="/proc/1/fd/1"
ip addr del $VIP
echo "$(date '+%F %T') $VIP down............" >> "$LOG_OUT"

vip_up.sh

1
2
3
4


#!/bin/bash
LOG_OUT="/proc/1/fd/1"
ip addr add $VIP
echo "$(date '+%F %T') $VIP up............." >> "$LOG_OUT"

这里要注意的是: >> $LOG_OUT 是将输出追加到/proc/1/fd/1文件中，这个文件是docker容器的标准输出文件。如果没有这个，echo的输出内容在docker logs -f keepalived下是看不到的。

entrypoint.sh

1
2
3
4
5
6
7
8


start_service(){
    envsubst < ./conf/keepalived.conf.tpl > ./conf/keepalived.conf
    echo "run keepalived...."
    exec keepalived -f ./conf/keepalived.conf -n -l -D -S 0
    echo "run done...."
}

start_service

exec 很重要，这样能保证keepalived进程在容器内以pid为1的方式运行，后续docker-compose down时，会发送SIGTERM信号给keepalived进程，而keepalived进程收到信号后，会先执行notify_stop脚本，然后再退出。

如果没有exec,直接keepalived -f ./conf/keepalived.conf -n -l -D -S 0, keepalived的进程就不会捕获到 SIGTERM信号。

./conf/keepalived.conf.tpl

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39


! Configuration File for keepalived

global_defs {
  # notification_email {
  #   acassen@firewall.loc
  #   failover@firewall.loc
  #   sysadmin@firewall.loc
  # }
  # notification_email_from Alexandre.Cassen@firewall.loc
  # smtp_server 192.168.200.1
  # smtp_connect_timeout 30
   router_id LVS_DEVEL
   vrrp_skip_check_adv_addr
  # vrrp_strict
}

vrrp_instance VI_1 {
    state $STATE
    interface $INTERFACE
    virtual_router_id $ROUTE_ID
    priority $PRIORITY
    advert_int 1
    authentication {
        auth_type PASS
        auth_pass testuser
    }

    virtual_ipaddress {
        $VIP
    }

    notify_master "/data/scripts/vip_up.sh"
    notify_backup "/data/scripts/vip_down.sh"
    notify_fault  "/data/scripts/vip_down.sh"
    notify_stop  "/data/scripts/vip_down.sh"

    # Allow packets addressed to the VIPs above to be received
    #accept
}

这里通过notify_master,notify_backup,notify_fault,notify_stop来调用vip_up.sh,vip_down.sh脚本主动添加/删除虚拟ip

docker-compose.yaml

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27


x-defaults: &defaults
  restart: unless-stopped
  environment:
    - TZ=Asia/Shanghai
    # 主备:MASTER/BACKUP
    - STATE=MASTER
    # 网卡名
    - INTERFACE=eth0
    # 优先级: master必须比mackup大，两者差小于20
    - PRIORITY=100
    # 监听时间间隔
    - INTERVAL=3
    # route_id
    - ROUTE_ID=52
    # 虚拟ip: 和实际ip在同一个网段内
    - VIP=172.16.0.250 dev eth0
services:
  keepalived:
    image: keepalived:1.0.0
    container_name: "keepalived"
    hostname: "keepalived"
    network_mode: "host"
    privileged: true
    cap_add:
      - NET_ADMIN
    stop_signal: SIGTERM
    <<: *defaults

这里注意的是:cap_add, stop_signal,这样在docker-compose down时，发送SIGTERM信号给keepalived进程。

主备测试

1
2
3


主服务器ip: 172.16.4.111
备服务器ip: 172.16.4.113
虚拟ip: 172.16.4.96

此时主服务器的docker-compose.yaml的配置为:

1
2
3
4
5
6
7
8
9


environment:
    - TZ=Asia/Shanghai
    - STATE=MASTER
    # 网卡名
    - INTERFACE=ens160
    - PRIORITY=100
    - INTERVAL=6
    - ROUTE_ID=52
    - VIP=172.16.4.96 dev ens160

备服务器的docker-compose.yaml的配置为:

1
2
3
4
5
6
7
8
9


environment:
    - TZ=Asia/Shanghai
    - STATE=BACKUP
    # 网卡名
    - INTERFACE=ens160
    - PRIORITY=90
    - INTERVAL=6
    - ROUTE_ID=52
    - VIP=172.16.4.96 dev ens160

正常启动

主备服务器上keepalived容器运行之后, 可以看到主服务器上有172.16.4.96这个虚拟ip, 而备服务器上没有。

主服务器网卡: ens160

1
2
3
4
5
6
7
8
9


ip addr show ens160
2: ens160: <BROADCAST,MULTICAST,UP,LOWER_UP> mtu 1500 qdisc mq state UP group default qlen 1000
    link/ether 00:50:56:83:b9:d7 brd ff:ff:ff:ff:ff:ff
    inet 172.16.4.111/22 brd 172.16.7.255 scope global noprefixroute ens160
       valid_lft forever preferred_lft forever
    inet 172.16.4.96/32 scope global ens160
       valid_lft forever preferred_lft forever
    inet6 fe80::e194:8abe:9eb7:bb02/64 scope link noprefixroute
       valid_lft forever preferred_lft forev

主服务器上的keepalived的docker logs -f keepalived日志为:

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29


ue Oct 14 16:00:22 2025: Assigned address 172.16.4.111 for interface ens160
Tue Oct 14 16:00:22 2025: Assigned address fe80::e194:8abe:9eb7:bb02 for interface ens160
Tue Oct 14 16:00:22 2025: Warning - script chk_web_service is not used
Tue Oct 14 16:00:22 2025: Registering gratuitous ARP shared channel
Tue Oct 14 16:00:22 2025: (VI_1) removing VIPs.
Tue Oct 14 16:00:22 2025: Startup complete
Tue Oct 14 16:00:22 2025: (VI_1) Entering BACKUP STATE (init)
Tue Oct 14 16:00:22 2025: VRRP sockpool: [ifindex(  2), family(IPv4), proto(112), fd(11,12) multicast, address(224.0.0.18)]
2025-10-14 16:00:22 172.16.4.96 dev ens160 down............
Tue Oct 14 16:00:22 2025: (VI_1) received lower priority (90) advert from 172.16.4.113 - discarding
Tue Oct 14 16:00:23 2025: (VI_1) received lower priority (90) advert from 172.16.4.113 - discarding
Tue Oct 14 16:00:24 2025: (VI_1) received lower priority (90) advert from 172.16.4.113 - discarding
Tue Oct 14 16:00:25 2025: (VI_1) received lower priority (90) advert from 172.16.4.113 - discarding
Tue Oct 14 16:00:25 2025: (VI_1) Receive advertisement timeout
Tue Oct 14 16:00:25 2025: (VI_1) Entering MASTER STATE
Tue Oct 14 16:00:25 2025: (VI_1) setting VIPs.
Tue Oct 14 16:00:25 2025: (VI_1) Sending/queueing gratuitous ARPs on ens160 for 172.16.4.96
Tue Oct 14 16:00:25 2025: Sending gratuitous ARP on ens160 for 172.16.4.96
Tue Oct 14 16:00:25 2025: Sending gratuitous ARP on ens160 for 172.16.4.96
Tue Oct 14 16:00:25 2025: Sending gratuitous ARP on ens160 for 172.16.4.96
Tue Oct 14 16:00:25 2025: Sending gratuitous ARP on ens160 for 172.16.4.96
Tue Oct 14 16:00:25 2025: Sending gratuitous ARP on ens160 for 172.16.4.96
2025-10-14 16:00:25 172.16.4.96 dev ens160 up.............
Tue Oct 14 16:00:30 2025: (VI_1) Sending/queueing gratuitous ARPs on ens160 for 172.16.4.96
Tue Oct 14 16:00:30 2025: Sending gratuitous ARP on ens160 for 172.16.4.96
Tue Oct 14 16:00:30 2025: Sending gratuitous ARP on ens160 for 172.16.4.96
Tue Oct 14 16:00:30 2025: Sending gratuitous ARP on ens160 for 172.16.4.96
Tue Oct 14 16:00:30 2025: Sending gratuitous ARP on ens160 for 172.16.4.96
Tue Oct 14 16:00:30 2025: Sending gratuitous ARP on ens160 for 172.16.4.96

备服务器网卡: ens160

1
2
3
4
5
6
7


ip addr show ens160
2: ens160: <BROADCAST,MULTICAST,UP,LOWER_UP> mtu 1500 qdisc mq state UP group default qlen 1000
    link/ether 00:50:56:83:0e:04 brd ff:ff:ff:ff:ff:ff
    inet 172.16.4.113/22 brd 172.16.7.255 scope global noprefixroute ens160
       valid_lft forever preferred_lft forever
    inet6 fe80::45a0:3144:4cf8:fb8d/64 scope link noprefixroute
       valid_lft forever preferred_lft forever

可以看到主服务器上有172.16.4.96这个虚拟ip, 而备服务器上没有,运行ok。

主服务器上`keepalived`容器停止

docker-compose down手动停止主服务器上的keepalived容器,其日志为:

1
2
3
4
5
6
7


ue Oct 14 16:14:09 2025: Stopping
Tue Oct 14 16:14:09 2025: (VI_1) sent 0 priority
Tue Oct 14 16:14:09 2025: (VI_1) removing VIPs.
2025-10-14 16:14:09 172.16.4.96 dev ens160 down............
Tue Oct 14 16:14:10 2025: Stopped - used (self/children) 0.047189/0.011739 user time, 0.151771/0.008893 system time
Tue Oct 14 16:14:10 2025: CPU usage (self/children) user: 0.005198/0.069158 system: 0.022745/0.163343
Tue Oct 14 16:14:10 2025: Stopped Keepalived v2.3.1 (05/24,2024

可以看到执行了vip_down.sh脚本,删除了虚拟ip, 主服务器网卡ens160上没有172.16.4.96这个ip了。

1
2
3
4
5
6
7


ip addr show ens160
2: ens160: <BROADCAST,MULTICAST,UP,LOWER_UP> mtu 1500 qdisc mq state UP group default qlen 1000
    link/ether 00:50:56:83:b9:d7 brd ff:ff:ff:ff:ff:ff
    inet 172.16.4.111/22 brd 172.16.7.255 scope global noprefixroute ens160
       valid_lft forever preferred_lft forever
    inet6 fe80::e194:8abe:9eb7:bb02/64 scope link noprefixroute
       valid_lft forever preferred_lft forever

备服务器的keepalived日志为:

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16


Oct 14 16:08:56 2025: (VI_1) Receive advertisement timeout
Tue Oct 14 16:08:56 2025: (VI_1) Entering MASTER STATE
Tue Oct 14 16:08:56 2025: (VI_1) setting VIPs.
Tue Oct 14 16:08:56 2025: (VI_1) Sending/queueing gratuitous ARPs on ens160 for 172.16.4.96
Tue Oct 14 16:08:56 2025: Sending gratuitous ARP on ens160 for 172.16.4.96
Tue Oct 14 16:08:56 2025: Sending gratuitous ARP on ens160 for 172.16.4.96
Tue Oct 14 16:08:56 2025: Sending gratuitous ARP on ens160 for 172.16.4.96
Tue Oct 14 16:08:56 2025: Sending gratuitous ARP on ens160 for 172.16.4.96
Tue Oct 14 16:08:56 2025: Sending gratuitous ARP on ens160 for 172.16.4.96
2025-10-14 16:08:56 172.16.4.96 dev ens160 up.............
Tue Oct 14 16:09:01 2025: (VI_1) Sending/queueing gratuitous ARPs on ens160 for 172.16.4.96
Tue Oct 14 16:09:01 2025: Sending gratuitous ARP on ens160 for 172.16.4.96
Tue Oct 14 16:09:01 2025: Sending gratuitous ARP on ens160 for 172.16.4.96
Tue Oct 14 16:09:01 2025: Sending gratuitous ARP on ens160 for 172.16.4.96
Tue Oct 14 16:09:01 2025: Sending gratuitous ARP on ens160 for 172.16.4.96
Tue Oct 14 16:09:01 2025: Sending gratuitous ARP on ens160 for 172.16.4.96

查看备服务器网卡ens160上是否有172.16.4.96这个ip

1
2
3
4
5
6
7
8
9


ip addr show ens160
2: ens160: <BROADCAST,MULTICAST,UP,LOWER_UP> mtu 1500 qdisc mq state UP group default qlen 1000
    link/ether 00:50:56:83:0e:04 brd ff:ff:ff:ff:ff:ff
    inet 172.16.4.113/22 brd 172.16.7.255 scope global noprefixroute ens160
       valid_lft forever preferred_lft forever
    inet 172.16.4.96/32 scope global ens160
       valid_lft forever preferred_lft forever
    inet6 fe80::45a0:3144:4cf8:fb8d/64 scope link noprefixroute
       valid_lft forever preferred_lft forever

备服务器上有172.16.4.96这个虚拟ip, 主服务器上没有此ip, 说明虚拟ip切换ok。

总结

当keepalived使用容器部署时，如果想要监听业务服务，通过业务服务的异常来切换主备服务器，需要在keepalived的配置文件中添加track_script项，指定监听的业务服务。因为容器是独立运行的，所以不能使用ps -aux|grep xxx来判断业务服务是否异常,可以检查tcp/udp/http端口来判断。
不想监听业务服务时，就可以采用上述方式。
如果keepalived的配置中不使用notify_stop这样的钩子，当主服务器keepalived容器停止时，网卡不会删除虚拟ip, 备服务器网卡也有虚拟ip，请求还是会到主服务器上。但是如果主服务器宕机, 那么就不会有这样的问题。
linux的内核参数配置/etc/sysctl.conf里net.ipv4.ip_nonlocal_bind=1。
