# 保活机制: 0,不保活;1,ping;2,pong, 默认: 1
modparam("websocket", "keepalive_mechanism", 0)

# 多长时间发送一个保活信息到空闲的websockt连接: 默认: 180,单位:秒
modparam("websocket", "keepalive_timeout", 180)

# 处理websocket 保活信息的进程数: 默认: 1
modparam("websocket", "keepalive_processes", 2)

# 多个处理保活进程运行的时间间隔: 默认: 1,单位:秒
modparam("websocket", "keepalive_interval", 2)

# ping/pong 应用程序数据: 默认: "header content"
modparam("websocket", "ping_application_data", "WebSockets rock")

# 支持的通过websocket发送的数据协议, 1,sip;2,msrp,默认1
modparam("websocket", "sub_protocols", 1)

# 配置跨域,0,不添加;1,添加"Access-Control-Allow-Origin: *";2,添加"Access-Control-Allow-Origin:"值为请求的"Origin";
modparam("websocket", "cors_mode", 2)

#是否打印websocket连接列表,默认0(不打印)
modparam("websocket", "verbose_list", 1)

# 每个时间处理进程运行间隔,默认1,单位秒
modparam("websocket", "timer_interval", 5)

# 待删除的连接多久之后开始删除,默认5,单位秒
modparam("websocket", "rm_delay_interval", 2)

  1
  2
  3
  4
  5
  6
  7
  8
  9
 10
 11
 12
 13
 14
 15
 16
 17
 18
 19
 20
 21
 22
 23
 24
 25
 26
 27
 28
 29
 30
 31
 32
 33
 34
 35
 36
 37
 38
 39
 40
 41
 42
 43
 44
 45
 46
 47
 48
 49
 50
 51
 52
 53
 54
 55
 56
 57
 58
 59
 60
 61
 62
 63
 64
 65
 66
 67
 68
 69
 70
 71
 72
 73
 74
 75
 76
 77
 78
 79
 80
 81
 82
 83
 84
 85
 86
 87
 88
 89
 90
 91
 92
 93
 94
 95
 96
 97
 98
 99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127
128
129
130
131
132
133
134
135
136
137
138
139
140
141
142
143
144
145
146
147
148
149
150
151
152
153
154
155
156
157
158
159
160
161
162
163
164
165
166
167
168
169
170
171
172
173
174
175
176
177
178
179
180
181
182
183
184

#!define WITH_MYSQL
#!define WITH_USRLOCDB
#!define WITH_NAT
#!define WITH_RTPENGINE
#!define WITH_JSONRPC

log_prefix="|$timef(%y-%m-%d %H:%M:%S)|$ci| "
listen=udp:172.16.4.111:5460
listen=udp:172.16.4.111:5461
listen=tcp:172.16.4.111:5461

#!ifdef WITH_MYSQL
loadmodule "db_mysql.so"
#!endif

#!ifdef WITH_JSONRPC
loadmodule "xhttp.so"
#!endif

#!ifdef WITH_NAT
loadmodule "nathelper.so"
#!ifdef WITH_RTPENGINE
loadmodule "rtpengine.so"
#!else
loadmodule "rtpproxy.so"
#!endif
#!endif


loadmodule "dialog.so"
modparam("dialog", "enable_stats", 1)

loadmodule "websocket.so"
modparam("websocket", "keepalive_mechanism", 1)
modparam("websocket", "keepalive_timeout", 30)
modparam("websocket", "keepalive_processes", 2)
modparam("websocket", "keepalive_interval", 2)
modparam("websocket", "ping_application_data", "WebSockets rock")




# ----- jsonrpcs params -----
modparam("jsonrpcs", "pretty_format", 1)
/* set the path to RPC fifo control file */
#modparam("jsonrpcs", "fifo_name", "/run/kamailio/kamailio_rpc.fifo")
#modparam("jsonrpcs", "fifo_mode", 0660)
#modparam("jsonrpcs", "fifo_group", "root")
#modparam("jsonrpcs", "fifo_user", "root")

/* set the path to RPC unix socket control file */
# modparam("jsonrpcs", "dgram_socket", "/run/kamailio/kamailio_rpc.sock")
#!ifdef WITH_JSONRPC
modparam("jsonrpcs", "transport", 7)
#!endif

# ----- ctl params -----
/* set the path to RPC unix socket control file */
# modparam("ctl", "binrpc", "unix:/run/kamailio/kamailio_ctl")

# ----- sanity params -----
modparam("sanity", "autodrop", 0)

# ----- tm params -----
# auto-discard branches from previous serial forking leg
modparam("tm", "failure_reply_mode", 3)
# default retransmission timeout: 30sec
modparam("tm", "fr_timer", 30000)
# default invite retransmission timeout after 1xx: 120sec
modparam("tm", "fr_inv_timer", 120000)

# ----- rr params -----
# set next param to 1 to add value to ;lr param (helps with some UAs)
modparam("rr", "enable_full_lr", 0)
# do not append from tag to the RR (no need for this script)
modparam("rr", "append_fromtag", 0)

# ----- registrar params -----
modparam("registrar", "method_filtering", 1)
/* uncomment the next line to disable parallel forking via location */
# modparam("registrar", "append_branches", 0)
/* uncomment the next line not to allow more than 10 contacts per AOR */
# modparam("registrar", "max_contacts", 10)
/* max value for expires of registrations */
modparam("registrar", "max_expires", 3600)
/* set it to 1 to enable GRUU */
modparam("registrar", "gruu_enabled", 0)
/* set it to 0 to disable Path handling */
modparam("registrar", "use_path", 1)
/* save Path even if not listed in Supported header */
modparam("registrar", "path_mode", 0)



# ----- usrloc params -----
modparam("usrloc", "timer_interval", 60)
modparam("usrloc", "timer_procs", 1)
modparam("usrloc", "use_domain", MULTIDOMAIN)
/* enable DB persistency for location entries */
#!ifdef WITH_USRLOCDB
modparam("usrloc", "db_url", DBURL)
modparam("usrloc", "db_mode", 0)
modparam("usrloc", "hash_size", 12)

#!endif


#!ifdef WITH_NAT
#!ifdef WITH_RTPENGINE
# ----- rtpengine params -----
modparam("rtpengine", "rtpengine_sock", "udp:172.16.4.111:2222")
#!else
# ----- rtpproxy params -----
modparam("rtpproxy", "rtpproxy_sock", "udp:127.0.0.1:7722")
#!endif
# ----- nathelper params -----
modparam("nathelper", "natping_interval", 30)
modparam("nathelper", "ping_nated_only", 1)
modparam("nathelper", "sipping_bflag", FLB_NATSIPPING)
modparam("nathelper", "sipping_from", "sip:pinger@kamailio.org")

# params needed for NAT traversal in other modules
modparam("nathelper|registrar", "received_avp", "$avp(RECEIVED)")
modparam("usrloc", "nat_bflag", FLB_NATB)
#!endif

...

# JSONRPC over HTTP(S) routing
#!ifdef WITH_JSONRPC
event_route[xhttp:request] {
        set_reply_close();
        set_reply_no_connect();
        #if(src_ip!=127.0.0.1) {
        #       xhttp_reply("403", "Forbidden", "text/html",
        #                       "<html><body>Not allowed from $si</body></html>");
        #       exit;
        #}
        #if ($hu =~ "^/RPC") {
        #       jsonrpc_dispatch();
        #       exit;
        #}
        if ($hdr(Upgrade)=~"websocket"
                        && $hdr(Connection)=~"Upgrade"
                        && $rm=~"GET") {

                # Validate Host - make sure the client is using the correct
                # alias for WebSockets
                if ($hdr(Host) == $null || !is_myself("sip:" + $hdr(Host))) {
                        xlog("L_WARN", "Bad host $hdr(Host)\n");
                        xhttp_reply("403", "Forbidden", "", "");
                        exit;
                }

                # Optional... validate Origin - make sure the client is from an
                # authorised website.  For example,
                #
                # if ($hdr(Origin) != "http://communicator.MY_DOMAIN"
                #     && $hdr(Origin) != "https://communicator.MY_DOMAIN") {
                #       xlog("L_WARN", "Unauthorised client $hdr(Origin)\n");
                #       xhttp_reply("403", "Forbidden", "", "");
                #       exit;
                # }

                # Optional... perform HTTP authentication

                # ws_handle_handshake() exits (no further configuration file
                # processing of the request) when complete in case of failure.
                if (ws_handle_handshake())
                {
                        # Optional... cache some information about the
                        # successful connection
                        xlog("L_INFO", "------------------ successful websocket connection \n");
                        exit;
                }
        }

        xlog("receive http request:\n");
        xhttp_reply("200", "OK", "text/html",
                                "<html><body>Wrong URL $hu</body></html>");

        exit;
}
#!endif

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18

route[REGISTRAR] {
        if (!is_method("REGISTER")) return;

        if(isflagset(FLT_NATS)) {
                setbflag(FLB_NATB);
#!ifdef WITH_NATSIPPING
                # do SIP NAT pinging
                setbflag(FLB_NATSIPPING);
#!endif
        }
        if (!save("location","0x02")) {
                sl_reply_error();
        }
        $fs="tcp:172.16.4.111:5460";
        $du="sip:172.16.4.114:5060;transport=tcp";
        route(RELAY);
        exit;
}

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18

route[REGISTRAR] {
        if (!is_method("REGISTER")) return;

        if(isflagset(FLT_NATS)) {
                setbflag(FLB_NATB);
#!ifdef WITH_NATSIPPING
                # do SIP NAT pinging
                setbflag(FLB_NATSIPPING);
#!endif
        }
        if (!save("location","0x02")) {
                sl_reply_error();
        }
        $fs="udp:172.16.4.111:5460";
        $du="sip:172.16.4.114:5060";
        route(RELAY);
        exit;
}

1
2
3
4
5
6
7
8
9

#!define WITH_TLS
alias="服务域名"
listen=tls:172.16.4.113:5462
log_prefix="|$timef(%y-%m-%d %H:%M:%S)|$ci| "

#!ifdef WITH_TLS
# ----- tls params -----
modparam("tls", "config", "/usr/local/etc/kamailio/tls.cfg")
#!endif

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13

[server:default]
method = TLSv1.2+
verify_certificate = no
require_certificate = no
private_key = /usr/local/etc/kamailio/域名.key
certificate = /usr/local/etc/kamailio/域名.pem
#ca_list = /usr/local/etc/kamailio/tls/cacert.pem
#crl = /usr/local/etc/kamailio/tls/crl.pem

[client:default]
#method = TLSv1.2+
verify_certificate = yes
require_certificate = yes

1

xlog("L_INFO","$si:$sp|$Ri:$Rp|$pr|$rm\n");
